Operation & Functions
Easy Operation
PLC based on Personalize control panel with large and advanced touch screen. Easy learning controlling panel is for simple operation with common sense.
In Built Instructions And Trouble Shooting
In-built instruction is provided for learning from the panel’s instructions. It would reduce the personnel training time by training and operating at the same time. It could provide flexible arrangement for personnel to attain the most efficient production to obviate the possibility of personnel movement. And in built trouble shooting is to assist operators to provide a prompt solution for operation problem and quickly reverted to avoid any shutdown cost.
30 Lots Cross Memory Module
Record the best labeling setting method for the best productivity. It is convenience for each production line of multiple products. Even for different person, it would also get into condition quickly.
Smart Label Length Setting Function
Quick set counter for desired length and perfect positioning of label.
Missing Label Set
Prevent product miss-labeled to ensure product accuracy while production and fulfill production QC procedure.
Production Preset Function
A built-in counter can either run freely keeping track of the number of products labeled to control the production or can be used in batch mode where the labeler automatically stops when the desired numbers of products have been labeled for efficient production management.
Auto Labeling Start Up Mode
While the power been switch on, the machine will enter labeling condition automatically for the same production as previous run and no need for further setting, this mode can tremendously save operator’s setting time and increase the production efficiency
Eight Synchronized Speeds Selection
Enable dispensing speed and conveyer speed fully synchronized for the most precise labeling effect.
Labeling Delay Function
It is Ideal for small scale adjustment and could do Calculate digitally for dispensing speed and position. It offers quick and easy set up through its advanced touch screen control in addition to its clean, precise and accurate labeling applications.
|
Supply Voltage |
220/110 VAC 50/60Hz 1Phase |
|
Power Consumption |
900VA |
|
Dispensing Speed |
30m/min max. |
|
Conveyor Speed |
30m/min max. |
|
Applicator Height |
150mm / 200mm |
|
Label Size |
150mm x 300mm max. |
|
Conveyor Width |
110mm |
|
Spool Diameter |
76mm |
|
Dimension |
2400mm (L) x 1500mm(W) x 1400mm(H) |
---Specifications are subject to change without prior notice----
